XTool N9EV For EV Cars Smart Wireless Scanner Diagnostic System 9.7 inch Tablet Support DoIP & CAN-FD Protocol

N9EV is a professional EV smart diagnostic system. Equipped with a 9.7-inch high-performance long-lasting tablet. The system supports Bluetooth communication, DoIP protocol, and CAN-FD protocol. N9EV supports most EV models in the market, and all the software including APP, diagnostic software, and operating system support online updates. N9EV covers extensive diagnostic functions, including Battery Pack Detection, Tesla diagnosis, Reading ECU Information, Reading/Clear DTCs, Reading Live Data, and IMMO functions more than 40 special functions.

Description

● Smart diagnostics system for U.S., European, Asian and Chinese electric, gas and diesel, and hybrid vehicles

● OEM-level diagnostics for TESLA, comes with dedicated connectors, support DTC Reading/Clearing, Data streaming, Bi-directional Control and Special Functions.

● Rapid analysis of EV high-voltage system including ability to read and erase codes and view live data

● Battery pack detection can be performed via OBD or directly with included specialty cables and jumpers to monitor the voltage and temperature for battery cell

● New models of battery pack can be added easily by CAN detection function for different manufacturer

● One-click to start the off-vehicle drive test of component, including compressor, DCDC, OBC and 48V motor

● Supports the latest communication protocols, including DoIP for Benz, Jaguar, Land Rover and BMW and CAN FD for GM

● Provides fault code guidance for VAG and BMW. Supports offline programming for Ford, Lincoln and Mazda; Online coding & programming for VAG BMW and Mercedes-Benz.

● Switch between EV diagnostic mode and regular diagnostic mode as you wish.

Top 9 Reasons to get the XTool NEXT N9EV

1. For TESLA Adapters with OEM-level diagnostic functions;
2. Battery Pack Detection;
3. 40 special functions
5. Add Topology Mapping function
6. ADAS calibration supported
7. supports Bluetooth communication, DoIP protocol, and CAN-FD protocol
8. Reading ECU Information

Battery Pack Detection

Support battery pack detection for most EV models in the market,for example Tesla,Renault,Volkswagen,Nissan etc.

Diagnostic for TESLA

You can perform DTC reading/clearing, read live data for Tesla Model X/Y/S/3 with the special adapter.

Topology Mapping function

Provides a visual representation of the communication status of each system in the vehicle during automatic scanning.

ADAS calibration supported

Support calibration function after replacing sensors such as camera and radar in ADAS system

IMMO function and other special

Support more than 40 Special functions

Special Function

1. Oil/Service/Maintenance Light
1. Electric Parking Brake
1. Throttle Relearn
1. Window Initialization
1. Tyre Pressure Reset
1. ABS Bleeding
1. Gearbox Match
1. Instrument Cluster
1. Immobilization/Key Programmer
1. BMS Reset
1. Headlight
1. Air Suspension
1. SAS Adjustment
1. Gear Learning
1. DPF
1. EEPROM Adapter
1. Injector Coding
1. Airbag Repair
1. Cylinder
1. Seat Configurations
1. Electronic Pump Activation
1. Disable Transportation
1. Performance Tire Upgrade
1. ECU configurations
1. A/F reset
1. Odometer Read
1. Reset control unit
1. Rain/Light Sensor
1. A/C Relearn
1. HV Battery
1. VGT Relearn
1. VIN
1. NOX Reset
1. FRM Reset
1. EGR Relearn
1. AdBlue Reset
1. SRS
1. Clutch Adaption
1. Speed Limit
1. Language change
1. Start/Stop
1. ADAS calibration
1. Battery Pack Detection

XTool NEXT N9EV Specification

Operating System:Android 10
Processor:Rock chip 4 Core 1.80GHz
Memory:2G RAM, 128 ROM (202207 version)
Display:9.7 inch capacitive touch screen with 1024×768P resolution
Communication Method:BT 4.2 | WIFI 2.4/5G
Connectivity:DB15 TO VAG | USB 3.0
Camera:Rear camera, 8.0 Megapixel, AF with Flashlight.
Sensors:Gravity Accelerometer, Ambient Light Sensor
Auto Input/Output:Microphone, Dual Speakers, 4-Band 3.5 mm stereo/standard headset jack
Battery:10000mAh, 3.7V lithium-polymer battery
Working Voltage:3.6 to 4.2V
Power Voltage:DC 12V
Working hours:12 hours
Operating Temperature:-10 to 40℃
Storage Temperature:-40 to 60℃
Humidity:<90%

Xtool NEXT N9EV Package list:

Accessories
Color Carton
Packing List
Certificate of Quality
Tool Case
Quick Guide
Main Units
VCI BOX
Charger DC 12V-3A
Charger cable
Test Connectors
DB15 to OBD2-16 Main Cable
USB3.0 To Type_B Main Cable
USB3.0 Data Cable (Connect to PC)
TESLA battery pack Adapter J1E04
TESLA Adapter 1-L1E02
TESLA Adapter 2-L1E03
Universal jumper cables
Universal jumper adapter cables
Battery Clamp Wire
Cigar Lighter Cable
