ANCEL S200 Car Smoke Leak Detector EVAP Pipe Smoking Generator Pipe Leakage Analyzer Tester EVAP System Diagnostic Tools

ANCEL S200 smoke leak detector supports multi-system testing, especially EVAP system

EVAP System Test
Intake System Test
Exhaust Systems Test
Crankcase system test
Car Sealing Test
Fuel Tank System Test
Turbo System Test
Various Pipe Fittings Test

ANCEL S200 smoke leak detector has a powerful pressure guage, easy to operate

1/2 psi pressure gauge and smoke regulator which helps you control the smoke effect easily and allowing you to estimate the size of the leak by the change of the gauge value.It will specifically mark where the leakage is coming from,improves the efficiency of diagnosis

how to work with ancel s200 smoke leak detector

Step1: Fill in 10ml-20ml test oil (baby oil) to the detector

Step2: Disconnect the pipe that needs to be connect with the detector

Step3: Connect detector with DC12V battery,device starts to work

Step4: The pipe will be filled with smoke,check the leak points

How to judge whether there is air leakage and the size of the air leakage port through the pressure gauge?

Ancel S200 is suitable for different types of cars, motorcycles, boats, etc

Overheat and anti-frost protaction

Specification

Power source:12V Fully Charged vehicle battery
Current:6A
Flow rate: <6 L/min
Pressure output:0.8-1.0 bar (0.8-14.5psi)

PACKIING LIST
