Freightliner Service Link 4.94.588 Diagnostics and Parameterization for Freightliner's Vehicles

Region: All regions
Languages: English
Type: Diagnostics and parameterization
Version: V4.94.588
OS: WinXP, Vista, Windows7
Quantity of CD: 1 DVD
Year: 2016

ServiceLink is a diagnostic and service tool that communicates with the various Electronic Control Units (ECUs) on Daimler Trucks North America LLC (DTNA) vehicles. You can view a variety of information, including information that is stored on the DTNA host (mainframe) computer.

ServiceLink version 4.94 supports diagnostics and parameterization for Freightliner’s newest class 8 vehicle.

ServiceLink 4.94 includes the following enhancements or new features:

• Supports the Controller Area Network (CAN) protocol for the Cascadia ECUs.

• Nexiq USB-Link adapter will handle all protocols, including the new CAN protocol.

• Supports four new ECUs for the Cascadia model, including:

- Signal detect and Actuation Module (SAM) Cab;
- SAM Chassis;
- Modular Switch Field (MSF);
- Central Gateway.

• Supports the following CAN ECUs functions:

- View faults and clear faults;
- Upgrading ECU software (Flashing);
- Parameters (except for the Central Gateway);
- MSF Switches.

• Provides updated Templates, including new templates that support the CAN ECUs. • Provides a new enhanced templates toolbar.

• Provides enhanced ECU List information and VIN reporting, including new Conflicting VIN dialog box. See Resolve a Vehicle Identification Number (VIN) Conflict for details.

This update to ServiceLink includes following:

This version of ServiceLink will remove support for ALL Cascadia vehicles.

DiagnosticLink Professional will be required to program or parameterize Cascadia ECUs. ServiceLink will continue to support the bulkhead module (BHM) for the M2, SD, C2, and RVM products. Legacy ECUs AGS2, ICU2, SDU (Step Deployment Unit), LBCU (Light Bar Control Unit) support will be maintained as well.

Release Highlights:

� The flash tab for the CHM/SHM/SEM/EXM is removed.
� Waiting time for disconnected online mode is significantly reduced.
� Improved ServiceLink installation process.
