ANCEL DS160 Features

- Lifetime Free Update online, you do not need any SD cards, cables or PC. Lifetime free updates, one-time payment, NO extra cost.

- Bidirectional Control test & (Active Tests) :Full control over various systems/ components to perform active tests like EVAP test,injector tests and etc

- OE-level All Systems Diagnostics : scan all available systems to read/erase fault codes, display live data or analog, active tests, retrieve ECU info.

- 30+ Special Functions: refer to the initial adaptation, self-learning, or auto-detection function,like battery register/replace,injector coding etc.

- Full 10 OBD Functions for All Cars to read/clear codes, turns off MILs and so on to do some simple diagnostic by yourself.

- One-Click AUTO-VIN&SCAN to do a comprehensive diagnostic to save your time,and convenience to use. 4 in 1 Live Data Graph to show the live vehicle conditions in text and graph to help you to analyze the abnormal parameter easily.

- Android 9.0 Operation System, make it simple for beginners. Stable and Smooth Performance farewell to slow loading thus enjoy fast diagnosis

- 5.5 inch Bright Full Touchscreen & Intuitive Interface, you can enjoy the clear and vibrant details of diagnostic data with fewer distractions.

- Built-in 32GB Store Memory & 4000mAh Battery

OE-Level Full System Scan & Diagnostic for Most OBDII/EOBD Vehicles

This option allows you to detect whether the car full system parameters are normal or not. It mainly including Drive System, Chassis System, Body System, Electrical system.

1.PCM(Drive System): Engine, Transmission, Transfer case, Electrical Machine Electronics, Fuel Pump, Gear, and more...

2. Chassis System: Accumulator Management Electronics, Steering, Integrated Chassis Management, Tyre Pressure Control, Active Cruise Control, Braking System, Suspension, TPMS and more...

3. BCM(Body System): SRS Airbag, Camera, Audio Radio, Gateway, Cluster Dashboard, Rain Sensors, Charging Interface Module, Parking Assistance, Power Control Unit, Touch box, Light, Battery Charging System, Head up Display, Wipe Control System, Roof, Seat & Door Motor system, Immobilizer, ABS ESP system, Air Condition.Electric Windows, Telephone, and more...

4. Electrical System: Including Centralized control system for engine and power transmission, Chassis integrated control and safety system,Intelligent body electronic system,Communication and information / entertainment system. Read and erase codes for all available systems, turn off MIL light (Indicator light), display live data in text, graph & analog for easy data review.

30 Reset Service for all cars ---lifetime free use

1,Oil Reset
The lightening of the car maintenance light indicates that the vehicle needs maintenance.Reset the mileage or driving time to zero after the maintenance, so the maintenance light will go out and the system will start a new maintenance cycle.

2,Elec.Throttle Adaption
Elec. Throttle Adaption is to utilize the car decoder to initialize the throttle actuator so that the learning value of the ECU returns to the initial state.

3,Steering Angle Reset
To reset the steering angle, first find the relative zero point position for the car to drive in straight line.Taking this position as reference,the ECU can calculate the accurate angle for left and right steering.

4,Battery Matching
This function enables you to perform a resetting operation on the monitoring unit of vehicle battery, in which the original low battery fault information will be cleared and battery matching will be done.

5,ABS Bleeding
When the ABS contains air, the ABS bleeding function must be performed to bleed the brake system to restore ABS brake sensitivity.

6,Break-pad Reset
lf the brake pad wears the brake pad sense line, the brake pad sense line sends a signal sense line to the on-board computer to replace the brake pad.After replacing the brake pad, you must reset the brake pad.Otherwise, the car alarms.

7,DPF Regeneration
DPF regeneration is used to clear PM(Particulate Matter) from the DPF filter through continuous combustion oxidation mode (such as high temperature heating combustion, fuel additive or catalyst reduce PM ignition combustion) to stabilize the filter performance.

8,Gear Learning
After the engine ECu, crankshaft position sensor,or crankshaft flywheel is replaced, or the DTC 'gear not learned' is present, gear learning must be performed.

9,IMMO Service
To prevent the car being used by unauthorized keys, the anti-theft key matching function must be performed so that the immobilizer control system on the car identifies and authorizes remote control keys to normally use the car.

10,Injector Coding
Write injector actual code or rewrite code in the ECU to the injector code of the corresponding cylinder so as to more accurately control or correct cylinder injection quantity.

11,TPMS Reset
Note:Cooperate with wireless tire pressure diagnosis tool to realize TPMS activation, programming and learning functions

12,Suspension Matching
This function can adjust the height of the body. When replacing the body height sensor in the air sus pension system, or control module or when the vehicle level is incorrect, you need to perform thisfunction to adjust the body height sensor for level calibration.

13,AFS Reset
This feature is used to initialize the adaptive headlamp system.

14,A/T Learning
This function can complete the gearbox self-learning to improve gear shifting quality.

15,Sunroof Initialization
This function can set the sunroof lock off, closed when it rains,sliding /tilting sunroof memory function,temperature threshold outside the car etc.

16,EGR Adaption
This function is used to learn the EGR valve after it is cleaned or replaced.

18,Airbag Reset
This function resets the airbag data to clear the airbag collision fault indicator.

19,Transport Mode
ln order to reduce power consumption, the following functions may be disabled, including limiting the vehicle speed, not waking up the door opening network, and disabling the remote control key, etc.At this time, the transport mode needs to be deactivated to restore the vehicle to normal.

20,A/F Reset
This function is applied to set or learn Air/Fuel ratio parameters.

21,Stop/Start Reset
This function is used to open or close the automatic start-stop function via setting the hidden function in ECU(provided that the vehicle has a hidden function and supported by hardware).

22,NOx Sensor Reset
NOx sensor is a sensor used to detect the content of nitrogen oxides (NOx) in engine exhaust. lf theNOx fault is re-initialized and the NOx catalytic converter is replaced, it is necessary to reset the catalytic converter learned value stored in the engine Ecu.

23,AdBlue Reset (Diesel Engine Exhaust Gas Filter)
After the diesel exhaust treatment fluid (car urea) is replaced or filled up, urea reset operation is required.

24,Seat Calibration
This function is applied to match the seats with memory function that are replaced and repaired.

25,Coolant Bleeding
Use this function to activate the electronic water pump before venting the cooling system.

26,Tyre Reset
This function is used to set the size parameters of the modified or replaced tire.

27,Windows Calibration
This feature is designed to perform door window matching to recover ECU initial memory, and recover the automatic ascending and descending function of power window.

28,Language Change
This function is used to change the system language of the vehicle central control panel.

.......

ALL 10 Mode OBDII/EOBD Functions:

Mode 01-Request current powertrain diagnostic data.

Mode 02-Request freeze frame information.

Mode 03-Request emissions-related diagnostic code

Mode 04-Clear/reset emissions-related diagnostic information.

Mode 05-Request oxygen sensor monitoring test results.

Mode 06-Request on-board monitoring test results for specific monitored systems.

Mode 07-Request emission-related diagnostic troublecodes detected during current or last completed driving cycle

Mode 08-Request control of on-board system, test or component.

Mode 09-Request vehicle information.

Mode 0A-Request emissions-related diagnostic troublecodes with permanent status after a clear/reset emission-related diagnostic information.

ECU CODING:

ANCEL DS160 supports the ECU replacement function, helps you match, learn, or code the newly replaced ECU.

The coding function is used to re-flash the vehicle control modules, it helps you flash the hidden features, or disable the annoying functions, and reprograms the adaptive data for certain components after repairs or replacements.

Such as set alarms and door locking, improve the driving performance and fuel efficiency of your car, disabling the automatic engine start/stop function, access the ECU for more hidden functions, etc.

BI-DIRECTIONAL CONTROL (ACTUATION TEST):

ANCEL DS160 scan tool with full-featured bi-directional control ability can actuate solenoids and actuators for active testing, send commands to many systems/components to test their working status, without using the vehicle controls.

Turn on the fuel pump, radiator fan, modulate the throttle, open/close windows, operate mirrors, turn on interior & exterior lights, sound horn, test door lock actuators etc.

FCA Auto Auth

Since 2023, Autel has released FCA Auto Auth Function for FREE on 2018 and newer FCA cars (Chrysler, Dodge, Jeep, Fiat) in the US, Canada and Mexico, which covers wider vehicles and helps technicians win more business.

Car-Key’s coding

Key matching, Reset Key, Relearn The Key, Add New Key for backup.

Cover 99% Global Car 100000+ Vehicles Supports

American cars: after 1996-newer

for BUICK, for CADILLAC,for CHEVROLET, for CHRYSLER, for DODGE, for FIAT(BRAZIL), for FORD, for FORD(AUSTRALIA) , for GM. for JEEP, for LINCOLI, for GM(BRAZIL)

European car:after 2002-newer

for ABARTH,for ALFA ROMEO,for AUDI, for BENTLEY,for BMW,for BUGATTI,for CITROEN, for DACIA,for EUROFORD, for FERRARI, for FIAT, for GAZ, for OPEL(SOUTHAFRICA),for IVECO.for JAGUAR,for LAMBORGHINI,for LANCIA,for LANDROVE,for MASERATI,for MAYBACH,for MERCEDES,for MINI,for OPEL,for PEUGEOT,for PORSCHE,for RENAULT, for ROLLSROYCE,for ROVER,for SAAB,for SEAT,for SKODA,for SMART,for SPRINTER, ,for VAUXHALL,for VAZ,for VOLVO,for VW ,for ASTONMARTIN,for UAZ

Asian cars:after 2002-newer

for ACURA,for DAEWOO,for DAIHATSU,for HOLDEN(AUSTRALIA),for HONDA,for HYUNDAI,for INFINITI,for ISUZU, for KIA,for LEXUS,for LUXGEN,for MAHINDRA,for MAHINDRA(INDIAN),for MARUTI,for MARUTI(INDIAN),for MAZDA,for MITSUBISHI ,for NISSAN,for GTR(NISSAN),for PERODUA,for PERODUA (MALAYSIA,for PROTON,for PROTON(MALAYSIA,for SAMSUNG,for SAIPA,for SSANGYONG,for SUBARU,for SUZUKI,for TATA,TATA(INDIAN), for TOYOTA ,for UNITED PAKISTAN

Chinese car:after 2008-newer

for BRILLIANCE,for BYD,for CHANGAN,for CHANGHE,for CHBUICK,for CHERY,for CHANGHE,for SUZUKI,for DFCIROEN,for ECUAID,for FAW(TIANJIN FOTON,for GONOW,for GWM, for HAFEI,for HAIMA,for JAC,for REFINE,for JOYLONG,for LIFAN ,for MG(SAIC,for QOROS,for MAXUS,for SGM,for SGMW,for XINKAI,for POLARSUN,for ZX,for AUTO,for ZOTYE,for SENOUA(BAIC)

20 Language Supports

English,French,Spanish,German,Russian,Korean,Japanese,Portuguese,Italian,Polish,Dutch,Hungarian,Finnish,Czech,Turkish,Greek,Arabic...

More convenient features to help you

Auto read VIN number: It can read VIN information automanually when you connect Car

Quickly Print Diagnostic Report:Print the diagnostic report of your car at any time
way print: Transfer the diagnostic report to the computer via USB, and then print it

Diagnostic Feedback:

When you encounter unsolvable problems or diagnostic software bugs during diagnosis,you can revert the most recent 20 test records to ANCEL Team.When we receive your feedback,we will analyze and troublshoot it in a timely manner,to improve the quality of our products and user experience.(please contact with us after leaving feedback,thank you)

4 in One Graphic Data Stream(4 Data Graphs shows in the Same Screen)

1.Combine: Displayed in graph merge status for data comparison.

2.Value: Displayed the parameters in values and shown in list format.

3.Customize: Customize the data stream option to be viewed. Tap the button, a pull-down list of the data stream items appears on the screen. Select the desired items (max4 items), and then screen will display the waveforms corresponding to these items immediately. If need to remove any items, just deselect them.

More Features, lifetime free update

Packing List
