FCAR F507 Heavy Duty Diesel Truck Car Diagnostic Tool ABS Transmission Pickup Bus Excavator OBD2 Automotive Diagnostic Scanner

The F507 HD code reader Pro is the ideal scan tools for truck repair, fleet management / maintenance staff, truck owner, truck driver, truck sale/lease/auction professional to have quick and easy access to vehicle electronic control units and sensors. It can easily read/remove fault codes, analyze live sensor data, and save or export into excel sheet. It covers all major truck's engine, transmission, ABS(break) and chasis or body control.

General Functions (Including OBD II Features):

1.Read ECU Information
2.Read and Erase Fault codes
3.Read Live Data
4.Read Freeze Frame
5.Graph Live Data
6.Screenshot Function
7.Class 4-Class 8 truck coverage featuring "Automatic Protocol Search".

Professional truck full system function for truck owner

1.Engine
2.Transmission
3.I/P-instrument panel
4.Drivetrain
5.Braking
6.Suspension
7.ESP-Electronic Stability Program system
(Including ABS-antilock brake system)
8.EPS-Electric Power Steering
9.Fuel
10.Immobilizer
11.SRS-Airbag
12.Headlamp Auto-leveling
13.BCM-body control module system
etc

(Transmission and ABS) function support models

ABS Support model

For BENDIX
FOr WABCO
For Haldex
For Wabash

Transmission Support Model

For Allison
For Eaton
For BENDIX
For ZF

Graph live data such as:

1.Engine speed
2.Engine ECU temperature
3.Percent acceleration pedal position
4.Engine intercooler temperature
5.Engine coolant temperature
6.Battery voltage
7.Alternator voltage
8.Ambient air temperature
9.Air inlet temperature
10.Set measurement units in SAE English/Metric.
11.Obtain updates from Fcar.com

FCAR F507 support models

HD Trucks:

for Freightliner, for Fuso, for GMC,
for truck, for Hino, for Isuzu,
for Iveco, for Kenworth, for Mack,
for Mercedes Truck, for Nissian UD,for Peterbilt,
for Sterling, for Western Star, for Volvo

Off road equipment

(additional adaptors might be required, but not included):
for BobCat, for Case, for Caterpillar,
for John Deere, for Komatsu, for Terex, for Volvo

OBD2 diagnostic support list

Car (US):

for Buick, for Cadillac, for Chevrolet,
for Chrysler, for Dodge, for Ford,
for GM, for GMC, for Lincoln,
for Jaguar,for Jeep, for Pontiac, for Saturn

Car (Europe):

for Audi, for Bentley, for BMW,
for Fiat, for Jaguar, for Land Rover,
for Mercedes Benz, for Mini, for Porsche,
for SAAB, for Smart, for Sprinter, for Volvo, for VW

Car (Asia):

for Acura, for Daewood, for Honda,
for Hyundai, for Infiniti, for Isuzu,
for Kia, for Lexus, for Mazda,
for Mitshubishi, for Nissan, for Scion,
for Subaru, for Suzuki, for Toyota;

Pickup (or Van):

for Silverado, for Corolado, for Ford (F150-750),
for Ford E-series, for Dodge RM 1500-5500,
for GMC, for Nissan Frontier, for Toyota

FCAR F507 Applications

1.Passenger cars, SUV’s Pickup Trucks, Vans,
Tow trucks, recreational vehicles, cement trucks,
dump trucks, garbage trucks, buses,
step vans, municipal vehicles, refrigerated trucks, and conventional trucks.Diesel engine.

2.Heavy-Duty Standard compliant construction, marine, agriculture, and other industrial machinery and equipment.

3.Works on most truck with SAE J1708 and SAE J1939 plus OBD2 automotive coverage.
The F506 offers OEM-level coverage for Hino, Mitsubishi Fuso, Isuzu and Nissan UD commercial vehicle models years 1992 to current. since 1992,Supports SAE J939,J1708,J1587andOBDII, .

More advantages of F507

1.This tool offers high quality lifetime free software updates and manufacturer support and services.

2.The F506 can scan and collect a predefined dataset from vehicle information or real-time sensor data, save and export to Excel formats--this is useful for collecting data and keeping records for analysis.

3.Display all sensor real time live data stream with chart.

4.Dimmable screen

5.It comes with OBD 16, Deutsch 6/9 pin Y type 2 connector.

6.SD memory card for extra storage

7.This tool can be used to screen for truck problems, avoiding towing fees and helping save time on diagnostic work.

8.Support ABS and gearbox functions of some models.

Free Lifetime Update:

Steps for FCAR 507 Update:

(The latest version is configured before the goods are sent, so there is no need to update after receiving the goods)

1. Visit www.fcar.com and find FCAR 507 .

2. Download Update Tool FCAR Update Utility, and install it in your windows laptop/desktop.

3. Open FCAR Update Utility and register an account.

4. Activate your FCAR 507 by entering the serial number in the rear.

5. Connect your FCAR 507 with your computer via the USB cable and click update menu in your FCAR 506 and then in the FCARUpdate Utility interface.

Please note, FCAR 507 is updated on the NEW FCAR website and NEW update tool. If you encountered unusual issues using the tool, please update it following the steps above.

Product Size:

Parcel Includes:

1.HD Reader Pro Unit
2.Main DB15 cable
3.6-9 Y Pin J1939 type 2 connector
4.OBD 16 Cable
5.USer Manual
6.Soft Nylon Carrying Case
