OBDSTAR X300 DP Plus Full Version with Key SIM Smart Key Emulator

Top 5 Reasons to Buy OBDSTAR X300DP Plus and Key SIM Simulator together:

1. Program Toyota 4D H chip smart key AKL
2. Calculate Hyundai Kia Porsche ID46 Pin code
3. 46, 4D Data Collection
4. Save money
5. Get Free Renault Convertor and FCA 12+8 Adapter

OBDSTAR X300 DP Plus Full Version(C Package):

Immobilizer+Mileage correction+Diagnosis+Special function (Oil rest +ABS+Battery matching+ECU programming+EPB+Throttle programming+Airbag rest+TPMS+Steering angle rest+OBDII+DPF+Injector code+Supension matching+Gear learning+CVT learning+EEPROM+Key renewing+ECU cloning)Adapter(P001 programmer+C001 circuit board+C002 circuit board+W001 data cable+W002 data cable+W003 data cable+Toyota smarkt key Emulator)+others(Ignition coil+Remote tester)

OBDSTAR X300 DP Plus Hardware Advantages:

1. Built-in VCI box
2. 8-inch touchscreen
3. Charge directly via OBD interface
4. Practical and high-end gift box
5. Industrial design with silicone case
6. Back bracket design:prop on the steering wheel or stand on the table
7. With 4 Toyota simulation keys (the fifth is coming soon)
8. P001 programmer: EEPROM adapter + RFID adapter + Key Renew adapter
9. Add the clip of reading SOP 8PIN EEPROM
10. C001/C002 circuit board to read and write chip data with welding
11. IMMO induction coil to detect the key induction coil failure of the vehicle.
12. Add wiring harness of ECU reading by OBD (for ECU cloning and switch activation)
13. One Year Free Update, after one year, the update fee is 499USD/year and you can buy the update subscription SP326-S

Software Advantages:

IMMO:

1. EEPROM
2. Renew Key
3. Key programming
4. Remote programming

Cluster Calibrate: wild vehicle coverage, please check the car list

Diagnosis: realize all vehicle systems diagnosis

Special Functions:

TPS/ ABS/ EPB/ DPF/ TPMS/ SRS Reset/ Fuel Injector/ Gear Learning/ Battery Matching/ ECU Programming/ Throttle Matching/ Oil Serrvice reset/ Steering Angle Reset/ Remote Manual Setting/ Electronic Steering Reset/ CVT Learning/Value Reset

ECU Clone:

1. ECU Clone, means ECU duplication.
The device copies all the data from the original vehicle ECU, and then writes all data copied into ECU with the same hardware to realize the same ECU function with the original vehicle.

2. Clone directly when replacing a new or a used ECU!
Without online matching in 4S store or removal of ECU bonding wire for reading and writing! Directly write without dismantling OBD!

3. Three features for ECU Clone:
A. Free of 4S online: break monopoly from 4S, benefiting automobile maintenance industry

B. Simplified operation procedures: realize foolproof operation

C. Non-dismantling with zero risks: read and write data without dismantling ECU

Switch Activation Function:

(Today many instruments or audio of vehicles activate secondary power supply to go into power-on status by relevant module CAN communication on the vehicle, but sometimes an instrument or an audio is separated from vehicle CANBUS network, causing startup failure when it needs to be repaired by an auto technician. This function can simulate CAN communication to activate secondary power supply, so the instrument or the audio enters into power-on status. In this way, it not only can test and verify the instrument or the audio, but also save an enormous cost for an auto technician to purchase a large number of startup platforms of various vehicles and wiring harnesses!)

Add“Help" Functions:

1. including built-in testable vehicle models, upgrade announcement, features, help notes and wiring diagrams, etc.
2. Carlist and upgrade announcement, all details are available on the device
3. Customers can look up the features or uniquely support functions on the device
4. Help notes: built-in help notes for each model or function
5. Wiring diagrams: built-in ECU wiring diagrams, more intuitionistic and convenient

OBDSTAR Key Sim 5 In 1 Key Simulator

Key SIM is a 5 in 1 key simulator can generate keys with our devices in the case of all keys lost, so the ignition switch can be turned on, and then a new smart key can be added and programmed with our devices.

Features:

• Supports 46, 4D Data Collection
• Supports 46 Transponder Password Calculation,Support models:
   Porsche(2005-2010) 46 Pincode decryption
   HYUNDAI/KIA 46 Pincode decryption,etc.
• Supports Toyota/Lexus 4D (94/D4, 98) Smart Key Simulation
• Supports Toyota/Lexus H (88/A8, A9, 39) Smart Key Simulation

More features are under development...

Package List:

Key Master DP Plus Unit
Main Wire
12V2A DC Charger
KIA-20
OBD II-16 Connector
HONDA-3
HYUNDAI/KIA-10
IMMO Induction Coil
Muti-functional Jumper
P001 Programmer Unit
C001/C002 Circuit Board
W001
W002
W003
RT100
94/D4 TOYOTA Simulation Smart Key
Configuration List/Certificate/Quick Start Guide Fold
Key SIM emualtor
Renault Convertor
FCA 12+8 Adapter
