NEW ARRIVAL! Foxwell's NEW PRODUCT IS COMING!

Notice any weird smells or fluids? Is your ride acting all wonky? Dashboard lighting up with CEL, BRAKE, AC, EVAP, STEERING, COOLANT, and more? Foxwell SD101 Pro is capable of promptly detecting and addressing leakage issues in various areas such as the engine, e-xhaust system, or vacuum lines. Preventing leak from escalating and leading to substantial repair costs when taken to a repair shop.

Why You Need a Smoke Leak Detector?

For example: 1. The rupture of the vacuum hose will cause the mixture to be too thick, the idle speed will increase, the hot car will not start well, the engine will surge during acceleration, the fuel consumption will increase significantly, and the exhaust pipe will emit black smoke.
2. Blocking will cause the idle speed to drift, and the idle speed is easy to stall.
3. Air leakage in the vacuum tube will cause the engine to run weakly

Comparison of FOXWELL SD101, SD101 PRO, SD201 and SD203

Precision Testing for Sensitive System

Crankcase System Test: Excessive pressure or corrosion of the crankcase is the main reason to damage the seal of the crankcase and cause oil leakage.

Intake System Test: Leakage in the air intake system will lead to insufficient intake of the car engine, which will result in scant engine power.

Car Sealing Test: Poor airtightness of the car may lead to a lot of inconvenience like inability to keep warm dusty, not soundproof, and not waterproof , etc.

Fuel Tank System Test: When there are gaps in the fuel tank and piping caused by improper installation or insufficient sealing of the fuel tank cap, it can cause leaks in the fuel tank system.

Turbo Test: The leakage of coolant would cause the engine to report high water temperature.Various Pipe Fittings Test: Smoke testing of brake hoses, power steering hoses, cooling system hoses, air conditioning system hoses, turbocharger hoses, fuel hoses, intake and exhaust system hoses, etc.

EVAP System Test: Leakage of the fuel evaporation system will cause fuel vapor to leak into the atmosphere, causing waste and pollution or unstable engine idling.

Exhaust System Test: Unpurified harmful gases to be discharged into the atmosphere or increase vehicle noise is the main disadvantage when leaks happened in the exhaust.

Integrated Air Pump, Highly Flexible

Engineered for ease, SD101 Pro eliminates the need for external gas sources, offering swift setup and immediate functionality. The built-in pump ensures efficient operation while enhancing portability, allowing you to effortlessly move the smoke tester automotive wherever it's needed.

A Must-have Flow Meter

Check out the float in the flow meter to see if there's any change - that helps confirm if there's a leak. Plus, it lets you figure out how big the leak is, down to the millimeter. Twist the knob a bit, and you can keep the smoke and air flow just right, meeting the testing needs of different car systems.

When you opt for the air mode, the flow meter helps you swiftly confirm if there's a leak. After that, switch to the smoke mode to pinpoint exactly where the leak is happening. This significantly boosts diagnostic efficiency and prevents the wastage of a large amount of smoke fluid, saving costs.

Product Features

Smoke leak detector, due to the characteristics of smoke, can perform leak detection on the entire pipeline, with visual operation, all-round, no dead corners, and no missing leakage points.

Short smoke output time: Output a large amount of smoke within 10 seconds, greatly reducing diagnostic time and improving work efficiency.

Simple and practical: With easy-to-use features and hook design, the conical adapter and airbag adapter can adapt to most air intakes.

Overheat and antifreeze protection: The smoke detector is equipped with the latest intelligent protection devices. When the temperature of the equipment exceeds 75 degrees Celsius, the power protection device will intelligently start and shut down to ensure the safety of the operator and equipment. If the device operates continuously for more than 15 minutes, it will be protected from overheating for a protection time greater than 10 minutes. This device is also suitable for low-temperature operation. Only car batteries with a full capacity of 12V are supported.

Precise Check for EVAP

Compatibility with most vehicles and systems, EVAP service kit and sealing plugs

The Foxwell SD101 PRO automotive smoke leak detector is suitable for detecting pipeline system leaks on cars, motorcycles, snowmobiles, beach bikes, light trucks, heavy-duty trucks, and speedboats.

How to Test It?

1. Inject 10ml-20ml of test oil into the smoke leak detector, filling 20ML of test fluid, under standard working conditions, can be used continuously for about 10 minutes; (about Smoke Oil: advise use the Baby oil)
2. Open the pipe that needs to be connected with the leak detector.
3. Install the airbag adapter into the sealed pipe and connect the device to the smoke conduit.
4. Connect the leak detector to the DC12V battery and the device will start working. NOTE: red clamp tp positive(+), and black clamp to negative(-)
5. The pipe will be filled with smoke and the leakage point will be checked.
6. Test the leaking pipeline, under the premise of sealing accurately, generally about 1 minute can be filled with smoke, if there is a leak, within 3 minutes, you can observe the results.

All in One, Meet Your Need!

The C-shaped embedded structure design has a stronger sense of hierarchy, making it not only a car repair tool, but also a handicraft.

A brand new smoke generation device with patented technology. Compared with peer products, at the same smoke concentration, it consumes less electricity and less e-liquid.

With the support of frequency conversion technology, even under high temperature protection, it can meet daily testing needs without the need to stop and wait. 10 minute work cycle

Compared to the 5-minute working cycle of peers, a longer testing time means it can meet the testing needs of more systems, such as the cab, large volume piping systems, water tanks, and so on.

Packing List
