Xhorse VAG MQB48 Add Key and All Keys Lost License for VVDI Key Tool Plus, VVDI2 & VVDI Prog


Function:
MQB Add key, All Keys Lost (AKL requires sync data from 3rd party)

Vehicle List:
VW: Golf7 CC Magotan T-ROC TAYRON Sagitar Bora Lamando Variant Lavida TiguanL Teramont
Audi: A3 Q2 Q3L
Skoda: Octavia, Kodiaq, Superb, Karoq

NEW UPDATE (April 2023)
VVDI Prog adds VAG IMMO4 MQB-LOCK (D70F35xx) read and write
VVDI2 Supports Immo4-NEC35xx dashboard which not support OBD(All key lost and new VDO)- require MQB48-NEC35xx(Lock) license

Cluster List:
MQB Cluster D70F3532 (A2C81589500)-A
Dash type: 560G920750

MQB cluster D70F3529
dash type 5G1920730B

MQB Cluster D70F3526 (A2C81589700)-C
dash type: 3G0920791B

MQB Cluster D70F3526 (A2C81589700)-B
dash type: 8V0920861

MQB Cluster D70F3526 (A2C81589700)-A
dash type:6C0920740A 6C0920940

MQB Cluster D70F3525 (A2C81589600)-B
dash type: 8V0920861

MQB Cluster D70F3525 (A2C81589600)-A
Dash type:56G920730C

Device affected:

VVDI2 + VVDI Prog (MUST have VVDI Prog to read immo data)

VVDI Key Tool Plus

if it applies on your vvdi2 only you have to have charged 4-5th and mqb to be able to load MQB2 and in vvdiprog.

Support read immo data for MQB48 type with NEC35xx chip which cannot read by OBD, support add key and all keys lost (need sync data)

Tips:
1. Add key: Use keytool plus , vvdi prog or mini prog to read immo data from dashboard (need remove the dashboard from car), then program key to car with the immo data.
2. For all key lost, program key will need immo data and sync data, it still need get sync data online and program key with both immo data and sync data.
3. There are two ways to read MQB immo data with vvdi prog/key tool plus, one is pin lift method the other is track cut method - might only be for that particular dashboard, probably not all will have track cut method
(Check video column for reference)
4. Check VAG NEC35xx locked dashboard part number list in Technical Support area.


How to activate VAG MQB48 license?

1. If you have VVDI2, make sure it is full version. Only full version can be authorized with license. Provide S/N to us to confirm if you are not sure it is full version or not.

2. Make sure your vvdi2/vvdi prog and key tool plus has registered with xhorse account.

For vvdi2 and vvdi prog, follow this way to register;
First, use the upgrade kit to identify vvdi2 or vvdi prog, click on the binding in the upper right corner, and it will come up with a QR code.  Then, find the cartoon character interface on the mobile APP, click on account in the lower right corner, there is a “combind device”, click “combind device”, and scan the QR code for binding.

For vvdi key tool plus, register and login in tablet.

3. After confirm 1 and 2, provide vvdi2+ vvdi prog or key tool plus serial number to us after payment. We will activate license within 24 hours.
