Operating  System

Android™ 4.4.2,  KitKat

Processor

Cortex-A9 processor  (1.5 GHz)

Memory

32GB

Display

7-inch LCD  capacitive touchscreen with 1024 x 600 resolution

Connectivity

Mini USB 2.0 • USB  2.0 • Wi-Fi • HDMI Type A • Micro SD card (supports up to  32GB)

Sensors

Light sensor for  brightness auto changing

Audio  input/output

Input: N/A • Output:  buzzer

Power and  Battery

3.7 V/5000 mAh  lithium-polymer battery • Charges via 5 VDC power supply

Tested Battery  Life

Around 7 hours of  continuous use

Battery Charging  Input

5 V/1.5  A

Power  Consumption

600 mA (LCD on with  default brightness, Wi-Fi on) @3.7 V

Operating  Temp.

-10 to 60°C(14 to  140°F)

Storage  Temp.

-20 to 70°C (-4 to  158°F)

Operating  Humidity

5% - 95%  non-condensing

Dimensions (W x H x  D)

270.8 mm (10.0”) x  176.0 mm (6.9”) x 36.0 mm (1.4”)

Net  Weight

885 g (2.31  lb.)

Protocols

ISO9141-2,  ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM,  ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant  CAN), SAE J2610,GM UART,UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0,  TP1.6
