Q: Is KTM100 available with Portuguese language?
A: KTM100 is available with English, Portuguese and Italian. Any other language you need, just contact uobdii.com customer service, we accept personal customization.

KTM100 Connection:
Connect KTM100 to the USB firstly or to the computer is optional.

Infineon Tircore:
KTM100 K-tag  cover more Infineon Tircore compared with other version of ktag.

Add power:
Choose “read Micro” to add power.

Some customers think KTM100 is fake:
One Chinese Company registered and applied for DIMSport patent, and then design hardware, so ktm100 is legal tool.

Q: V7 K-tag can program ECU via Tricore?
A: Yes, our Ktag KTM100 software video is the test result of the VAG Bosch EDC17U01 TC1766 via Tricore.
https://www.youtube.com/watch?v=G6zKIO6hF2s
Q: Does K-tag 7.003 cover BMW F-series?
A: Yes, you are able to check the vehicle list here.

Q: KTM100 got prompt “Error during the server connector”
A: ignore the prompt, just click “OK”

Q: Does it deduct tokens when KTM100 read ECU data?
A: Same as KESS, it only deducts tokens when KTM100 write map file.

Q: What’s the difference between EDC17 and MED17?
A: EDC17 is gasoline car.
MED17 is diesel car, the models can be found out at ECU.
K-TAG KTM100 V2.13 Firmware V7.003 ECU programmer adds some vehicle model EDC17 ECUs, please check below:

BMW
EDC17C41   TC1797
EDC17CP45  TC1797
EDC17C50   TC1797
EDC17C56   TC1797
EDC17CP49  TC1797
MEVD172G  TC1797
MEDV1725   TC1797

VW
EDC17C46   TC1797
EDC17C44   TC1797
MED17.1.6   TC1797
MED17.5.21  TC1782
MED17.5.5   TC1767
ME17.5.24   TC1724
MED17.1.1   TC1797

Volvo
EDC17CP48  TC1797

Jaguar
MED17.8.31   TC1797

Opel
EDC17C59   TC1767

Mercedes Benz
EDC17C46    TC1797
MED17.7.2    TC1797
EDC17CP57   TC1793
EDC17C66    TC1793

Ford
EDC17C10    TC1797

Ferrari
MED17.3.4    TC1797

McLaren
ME17.8.3      TC1797

Renault
ME17.9.20     TC1782

More two problems as follows:
Problem one: K-Tag KTM100 FWV7.003 Connection error E000079 (Fixed)
After successfully installed the Ktag KTM100 V2.13 software on Win XP laptop and tried to select ECU to read and write. The software displays no ECU options under “Option” tab (all options are in gray). Meanwhile, the KTM100 software reported an error:
“Initialization…
Interface connected…
Firmware Version: v7.3 build:0000
Error 【E000079】Customer Code Invalid”

Possible causes:

1.Internet connection have not been disabled
2.Ktag driver is not well installed
3.There is no power supply fed to the Ktag ecu programmer
4.TF card and Shrapnel has poor connection

Solution:

1.Please disable internet/network connection before installing software. THIS IS VERY IMPORTANT!!!

2. Make sure Ktag KTM100 driver is well installed.
Open My Computer>>Manager>>Device Manager>>Universal Serial Bus
controllers>>DimSport-New Trasdata Device to check the good communication between K-tag and computer.
3.Make sure there is a power supply fed to the Ktag ECU tuning kit.

4.If all the previous conditions are no problem, then the problem lies on the TF card. Make the shrapnel firmly attached to the TF card.

In our customer’s case, the TF card is loose connection. He higher the shrapnel to make it firmly attached to the TF card, then the problem was solved.

Problem two:  K-TAG KTM100 V2.13 Firmware7.003 option menu empty (fixed)

Problem:
I installed KTM100 software on PC with XP SP3 system, software was loaded OK. The Ktag ECU programming tool is recognized by PC and it read the vehicle information. But in the “Option” menu the windows to set language and another is all white (error screenshots token below). I changes on 3 other PC but the problem is on all.

Reason:
The operating system is not compatible with Ktag KTM100 software. (ONLY REASON)

Solution:

Change our Windows XP SP3 operation system and re-install the KTM100 ECU tuning software.
http://www.chinaautodiag.com/html/ghost-windows-xp-professional-sp3-free-download-and-installation-6476.html

Then follow the KTM100 V2.13 software installation video guide.

Problem is settled.
BTW, Customer feedback: With your XP operating system, all the menu option displays.
