XTUNER Bluetooth CVD-6 on Android Commercial Vehicle Diagnostic Adapter XTuner CVD Heavy Duty Scanner

XTUNER CVD-6 Description :

The Bluetooth XTUNER CVD-6 is the China' first commercial vehicle diagnostic adapter based on Android. CVD-6 is an electronic device that connects to the on-board ECU computers of truck, fire engine and motorhome, then transmits information via Bluetooth to the XTUNER CVD application. The CVD-6 adapter works with Class 3 - 8 heavy duty trucks with 9-pin/6-pin Dutch diagnostic port.

Top 6 reason to choose XTUNER CVD-6:1. Xtuner CVD-6 is the China first commercial vehicle diagnostic adapter based on Android,  is a high-end and new style commercial vehicle diagnostic adapter developed by TDIntel.2. CVD-6 is an electronic device that connects to the on-board ECU computers of truck, fire engine and motorhome, then transmits information via Bluetooth to the XTUNER CVD application.3. The CVD-6 adapter works with Class 3 - 8 heavy duty trucks with 9-pin/6-pin Dutch diagnostic port. Workable Brands includes: Allison, Bendix, Caterpillar, Cummins, Detroit Diesel, Freightliner, Fuller, Haldex, International, John Deere, Mack, Mack 4, Mercedes Benz, Paccar, Pi, Psi, Takata, Volvo, Wabco, ZFMeritor, etc.4. XTUNER CVD-6 Adapter is made of industrial grade materials, is strong and durable.5. With Intelligent two-color lights, the color of CVD is not the same in different communication status, which can facilitate the customer to determine the communication status of CVD-6.

CVD-6/CVD-9 update information (Jan 8th, 2018):DISPLAY UI upgrade to V4.6 1. Optimize UI display2. Add retrive password function3. Improve diagnostic capabilities and communication layer stability4. New model software update reminder.5. Optimization of diagnostic data flow interface interaction.6. New freeze data stream refresh function.7. Add history reminder for diagnostic menu click.8. Optimize APP installation package size.9. Add datastream meter display10. fix some bugs. CVDOBD Upgrade to V13.41. Improve the J1708 systems for VOLVO trucks. XTUNER CVD-9/6 UI V4.0 releasedUpdate information:1. Add test report for DTC, system information and data list function.2. Add data list record and play function.3. Add screen recording function (support Android 5.0 and above).4. Support 6 languages: English, Deutsch, Spanish, French, Korean, Polish.5. Add DTC online searching by Google or Baidu.6. Add data wave display for data list function.7. Add the User information management.8. Improve the setting function.9. Improve the communication layer for diagnostic function.

XTUNER CVD-9/6 OBD Diagnose software V13.1 releasedUpdate information:1. Add data groups for data list function.2. Improve the diagnostic functions for J1939 systems.3. Improve the diagnostic functions for J1708 systems. Xtuner CVD-6 Features:The vehicle model and engine type can be detected automatically.OE Level Fault Code Information: display 99% of Heavy-Duty fault codes with detailed descriptions on the OEM level component and trailer .Fault Management: to clear faults and diagnose all vehicle components in a single, easy to use application.

XTUNER CVD-6 Vehicle List:Year Model: 2000 – newestCompatible Protocol: J1708Allison, Bendix, Caterpillar, Cummins, Detroit Diesel, Freightliner, Fuller, Haldex, International, John Deere, Mack, Mack 4, Mercedes Benz, Paccar, Pi, Psi, Takata, Volvo, Wabco, ZFMeritor, etc.

XTUNER CVD-6 Data Wave Show:Wave Form

Support wave display, can simultaneously analyze the situation of 4 data streams to let customers fully understand the changes in data streams under any vehicle conditions. Wave DashboardSupport meter display, which is convinent for customer to understand scope in change of data stream under any vehicle conditions and immediately find the problematic sensors and components according to the warning range of settings.

Wave Form AnalysisProfessional analysis software for data stream wave form, can analyze 4 data streams at the same time. By overlaying and comparing forms, customers can easily and immediately find the vehicle fault.

How to use XTUNER CVD6 Heavy Duty Scanner to diagnose heavy duty trucks on Android phone?

Step 1:Download “CVD OBD” on APP store.

Step 2:Choose protocol type among Auto scan diagnose,SAE-J1708 diagnose,SAE- J1939 diagnose

Step 3:Choose Engine type

Step 4:Choose function you want incl. system information, trouble code, data list

Step 5:Read out system information

Read out trouble codes

Read out data list

XTUNER CVD-6 Software:

PackageList:

1pc x XTUNER CVD-6 Commercial Truck Vehicle Diagnostic Adapter
