TOPDON Smartdiag Mini Bluetooth OBD2 Scanner Auto Diagnostic Tool Code Reader Easydiag OBD Automotive Tool as Thinkdiag Mini

SmartDiag mini is a portable, economical vehicle fault diagnosis tool suitable for DIY personal users and small repair shops.

SmartDiag mini is composed of a diagnostic connector and an APP. It is connected to the vehicle diagnostic seat through the connector, and wirelessly communicates with a smartphone or tablet via Bluetooth, so that the client software and diagnostic software can be installed on the smart terminal to diagnose the automobile fault.

Supported models: Compatible with all models supporting the OBD II protocol after 1996

FREE Lifetime:

OBDII Diagnostics

For the 1st Year: FREE to use any Vehicle Diagnostic Software / Maintenance Software of your choice (5 in total). You can choose any ONE below:

√ 5*Vehicle Diagnostic Software
√  5*Maintenance Software
√  1*Vehicle Diagnostic Software + 4*Maintenance Software
√  2*Vehicle Diagnostic Software + 3*Maintenance Software
√  3*Vehicle Diagnostic Software + 2*Maintenance Software
√  4*Vehicle Diagnostic Software + 1*Maintenance Software
*Yearly 19.95 USD / each for extra software module.

For the 2nd Year:

√ 19.95 USD / each for Vehicle Diagnostic Software

√ 19.95 USD / each for Maintenance Software

Support Multi-language:

China,English,Italian,German,Japanese,Russian,French,Spanish, Portuguese.

Full System Car Diagnostic Tools

This multipurpose obd2 scan tool can scan and clear DTCs, and display Live Data in all available car systems, of over 120 vehicle brands worldwide with one touch for Engine, Transmission, Airbag, ABS, ESP, TPMS, Immobilizer, Gateway, Steering, Radio, Air Conditioning, etc.

*The complete systems vary from different cars.

1.For Engine System: Take a look at the most common issues relating to car engine failures as: Poor lubrication, Failing oil pump, Oil deposits and debris, Inadequate fuel and air compression, Leaking engine coolant, Blocked engine radiators, Prolonged engine detonation, Damaged oxygen sensors, Aged spark plugs, etc., to avoid engine breakdowns, or even require a brand-new one.
2.For SRS System: Check every aspect of your airbag system to pinpoint the trouble area such as: a bad seat belt, a corroded crash sensor, or some water intrusion in a connector, identifying issues you'd otherwise need a mechanic to correct.
3.For ABS System: Diagnose what is causing the ABS lights to come on. Some of the common problems include: blown sensor fuse, low brake fluids, and faulty sensor. This is important to prevent the wheels being out of the control of locking and skidding.
4.For Transmission System: Have proper care and attention to ensure its long lasting operation in case of: Grinding or shaking sensation in gear, Whining, humming or clunking noises, Burning smells, Gears Slipping, Low or Leaking Transmission Fluid, and such.
5.For TPMS System: Verify common TPMS problem such as: Low tire pressure, Faulty in tire pressure monitor control module, Unknown tire sensor, Failure to identify tire sensor.
6.And more.

OBD2 Scanner Professional Support 15 Special Service Functions

The Smartdiag Mini professional Bluetooth OBD2 scanner supports 15 commonly used special reset functions, allowing you to quickly access the vehicle system for various scheduled services, maintenance and reset performance, eliminating the need to reset the car after solving common problems Troubles. It is one of the favorite OBD2 Scanner for personal DIY owners and various repair shops. Listed some commonly used special reset services for your reference:

1.Oil Service Light Reset:
Perform reset for the Engine Oil Life system, which calculates an optimal oil life change interval depending on the vehicle driving conditions and climate.

2.DPF Diesel Particulate Filter Regeneration:
Manage DPF regeneration, DPF component replacement teach-in and DPF teach-in after replacing the engine control unit.

3.SAS Steering Angel Sensor Reset:
perform calibration for the Steering Angle Sensor, which permanently stores the current steering wheel position as the straight-ahead position in the sensor EEPROM.

4.EPB Electronic Park Brake Reset:
Maintain the electronic braking system safely and effectively by deactivating and activating the brake control system, setting brakes after disc or pad replacement, etc.

5.TPMS Tire Pressure Monitoring System Reset:
quickly look up the tire sensor IDs from the vehicle's ECU, as well as to perform TPMS replacement and sensor test.

6.IMMO Service:
Disable the lost vehicle keys and program the replacement key fob.

7.Injector Coding:
diesel infector code need programming ID and parameters to the ECU for accurate communication and Injection control system.

ETC......

OBDII/EOBD Full Functions

• Mode $01 Read dynamic data flow, fault light indication, ready status
• Mode $02 Query frozen frame data
• Mode $03 Read current fault code
• Mode $04 Clear the fault code
• Mode $05 Oxygen sensor detection test
• Mode $06 Specific monitoring system vehicle monitoring test
• Mode $07 Read pending fault code
• Mode $08 Control of in-vehicle systems or components
• Mode $09 Read vehicle information
• Mode $0A Read permanent fault code

Support Mobile Phone&Tablet Computer

Android:5.0
IOS:9.0
Smartdiag Mini OBD2 Diagnostic Tool is suitable for Mobile phones, tablet computer that meet the above version information. When the adapter is connected to the car, you only need to detect and diagnose your vehicle through the mobile phone's Bluetooth 4.2 and APP. It is suitable for most DIY car owners and maintenance and repair car stores on the market.

Support Cover Up to Over 115 Major Vehicle Manufacturers From America, Europe and Asia:

ThinkDiag mini can be detect almost all vehicles in America, Europe, and Asia Pacific regions with OBD port. Please click here to check the Vehicle Coverage.

Examples are as follows:

European and American area

Ford Europe, Mercedes-Benz commercial vehicles, MINI, West, Audi, GMSA, Fiat, Opel, GAZ, Peugeot, Volkswagen, Porsche, Citroen, Skoda, Rover, Land Rover, Volvo, VAZ, Renault, Elves, Mercedes-Benz, Jaguar, Dacia, Lancia, BMW, Romeo, Saab, Ford, Chrysler, GM.

Asia-pacific region

Thailand Isuzu, Acura, Daewoo, Jianghuai cars (GM), Ssangyong, Infiniti, Proton, Honda, Mazda, Perodua, Jiangling Automobile, Mahindra (MAHINDRA), Isuzu, Suzuki, Byd auto, Chery cars, Toyota, Nissan, Kia, The Car, The Great Wall in cars, Daihatsu, Changan automobile, Geely automobile, Xiamen Jinlong, Zhongxing automobile, Hafei automobile, New Kay, Gonow automobile, Changhe automobile, Hyundai, Liuzhou Wuling, Subaru, Xiali, Australia ford, Mitsubishi, TATA, Zhongtai automobile, Horton, MARUTI, Lexus.

EASY TO USE

Professional Automotive Scanner Diagnose Report

SmartDiag Mini provides professional diagnostic reports. After the diagnosis, a complete diagnostic report will be automatically generated to clearly understand any malfunction of the vehicle. You can also share the report to the community, facebook, twitter, to facilitate sharing and discussion with friends.

Automatic VIN Retrieval in Seconds

This advanced car scanner has a one-touch AutoVIN option, to help you automatically identify the vehicle, match the proper diagnostic software, for a quick and precise scan.

All you need is to plug the obd2 scanner's adapter in, and run AutoVIN with a single touch.

Easy Live Data Stream in Graphic

This obd2 code reader presents the real-time data stream in three modes: a. Numbers and lists (default); b. Wave patterns; c. Merged graph (max 4 data can be merged).

So you can quickly identify if the data are in normal conditions / ranges or not.

The data can also be recorded, and saved as a diagnostic report for further analysis.
