Bitbox Dongle & Bitbox Module for China Full Work with Scanmatik 2 PRO SM2 Pro SM3 PRO Programmer

Set of 6 BitBox modules with all we have support for chineese cars.

Package includes:

- China Bosch MG1 Petrol
- China Bosch Petrol
- China Delphi Petrol
- China Diesel CAN
- China Siemens Petrol
- China LinControl Petrol

Bitbox Dongle & Bitbox Module for China Bosch MG1 Petrol

FIDs: 420, 421, 422, 423, 424, 425, 427, 428, 429, 430, 431, 446

Software module for reading and writing Bosch MG1 ECUs internal flash memory for China vehicles with petrol engines.

• China Bosch MG1UA008 BAIC/DFM/FAW/SWM/SGMW (FID: 427) with SPC574 2.5Mb R/W/CS

• China Bosch MG1UA008 Chery/Jetour (FID: 431) with SPC574 2.5Mb R/W/CS

• China Bosch MG1UA008 Great Wall/Haval (FID: 423) with SPC574 2.5Mb R/W/CS

• China Bosch MG1UA008/UP8 JAC/Geely/Changan (FID: 424) with SPC574 2.5Mb R/W/CS

• China Bosch MG1US008 BAIC (FID: 430) with TC277 4Mb R/W/CS

• China Bosch MG1US008 Chery/Exeed (FID: 421) with TC277 4Mb R/W/CS

• China Bosch MG1US008 Dongfeng/FAW (FID: 422) with TC277 4Mb R/W/CS

• China Bosch MG1US008 Great Wall/Haval (FID: 420) with TC277 4Mb R/W/CS

• China Bosch MG1US008 SAIC (FID: 429) with TC277 4Mb R/W/CS

• China Bosch MG1US008/UD8 Changan (FID: 425) with TC277 4Mb R/W/CS

• China Bosch MG1US008/UD8 GAC (FID: 446) with TC277 4Mb R/W/CS

• China Bosch MG1US708 Geely/Lynk&Co (FID: 428) with TC387QP 10Mb R/W/CS

Attention! Reading and writing areas described in Manual for every ECU type. Some ECU types need direct connection on the BENCH. Writing of BAD mod file can completely brick an ECU with no recovery possible.

Other ECU types will be added ASAP.

Attention! We also have BitEdit module for editing

Bitbox Dongle & Bitbox Module China Bosch Petrol

BitBox is a flasher that allows identification, reading and writing of ECU internal flash memory for various purposes. It works via CAN bus or K-line data interfaces using an J2534 Pass-thru adapter.

The package consists of a protection USB dongle and software with a set of plug-ins — software modules. The existing modular system allows to get access to needed software functions without excessive cost. The program has a client-server architecture and needs to be connected to the Internet. Activation of additional modules is also possible in the automatic mode via the Internet.

Module China Bosch Petrol

FID: 57, 60, 63, 68, 75, 76, 81, 82, 84, 127, 233, 234, 239, 338

Software module for reading and writing Bosch ECUs internal flash memory for China vehicles with petrol engines.

*Bosch M7.9.7 (FID: 239) with C167 512kb VR/W/CS

*Bosch ME7.9.7 (FID: 68) with C167 1Mb VR/W/CS

*Bosch ME7.9.7 (FID: 68) with C167 1Mb VR/W/CS

*Bosch M(E)7.9.71 (FID: 233) with ST10F275 832Kb VR/W/CS

*Bosch M7.8 (FID: 57) with ST10F275 832Kb VR/W/CS

*Bosch M7.8.17 FAW (FID:414) SPC563 1.5MB R/W/CS

*Bosch ME7.8.8 (FID: 63) with ST10F275 832Kb K-line VR/W/CS

*Bosch ME7.8.8 (FID: 76) with ST10F275 832Kb CAN VR/W/CS

*Bosch ME17.8.8 (FID: 60) with Infineon TC1728 1.5Mb R/W/CS

*Bosch ME17.8.8 Saic (FID: 127) with Infineon TC1728 1.5Mb R/W/CS

*Bosch ME17.8.8 Vantage (FID: 166) with Infineon TC1728 1.5Mb R/W/CS

*Bosch ME17.8.8.1 (FID: 82) with Infineon TC1728 1.5Mb R/W/CS

*Bosch ME17.8.8.1 Geely (FID: 84) with Infineon TC1728 1.5Mb R(bench)/W/CS

*Bosch MED17.8.10 Haval (FID: 122) with Infineon TC1728 1.5Mb R/W/CS /TEST/

*Bosch MED17.8.10 Geely (FID: 234) with Infineon TC1728 1.5Mb R/W/CS /TEST/

*Bosch MED17.8.10 Chery (FID: 338) with Infineon TC1782 2.5Mb R/W/CS

*BYD TB10 Type1 (FID: 81) with Renesas SH72531 1.25Mb R/W/CS

*BYD TB10 Type2 (FID: 148) with Renesas SH72531 1.25Mb VR/W/CS

*Bosch M7.8/ME7.8.8 BSL (FID: 75) with ST10F275 832Kb K-line R/CS*

* - adapter BITS001 required. Tested only with J2534 Tactrix Openport 2.0

Bitbox Dongle & Bitbox Module China Delphi Petrol

BitBox is a flasher that allows identification, reading and writing of ECU internal flash memory for various purposes. It works via CAN bus or K-line data interfaces using an J2534 Pass-thru adapter.

The package consists of a protection USB dongle and software with a set of plug-ins — software modules. The existing modular system allows to get access to needed software functions without excessive cost. The program has a client-server architecture and needs to be connected to the Internet. Activation of additional modules is also possible in the automatic mode via the Internet.

Module China Delphi Petrol

FID: 51, 52, 53, 54, 55, 56, 58, 59, 61, 86, 146, 158, 408, 455, 456, 457, 462, 463, 464, 468, 472, 476, 481, 482, 483, 502

Software module for reading and writing Delphi ECUs internal flash memory for China vehicles with petrol engines.

*Delphi MT20U (FID: 51) with Motorola MC912DT128 128Kb - R/W/CS

*Delphi MT20U2 (FID: 59) with Motorola MC9S12KG256 256Kb - R/W/CS

*Delphi MT22.1 (FID: 52) with Motorola MC9S12XEP768 768Kb - R/W/CS

*Delphi MT22.1 IAC (FID: 158) with Motorola MC9S12XEQ512 512Kb - R/W/CS

*Delphi MT22U (FID: 53) with Motorola MC9S12XET256 256Kb - R/W/CS

*Delphi MT20UED (FID: 58) with Motorola MC9S12KG256 256Kb - R/W/CS

*Delphi MT22.1.1 HW1 (FID: 54) with Motorola MC9S12XET256 256Kb - R/W/CS

*Delphi MT22.3 Chery (FID: 463) with NXP SPC563M64 1.5Mb - R/W/CS

*Delphi MT22.3 JAC (FID: 502) with NXP SPC563M64 1.5Mb - R/W/CS

*Delphi MT22.3/MT22.5 Lifan (FID: 462) with NXP SPC563M64 1.5Mb - R/W/CS

*Delphi MT22.3 New Longma (FID: 464) with NXP SPC563M64 1.5Mb - R/W/CS

*Delphi MT34 (FID: 55) with Infineon Tricore + EXT.Flash 1Mb - R/W/noCS - test

*Delphi MT62.1 K-line (FID: 56) with NXP SPC5634 1.5Mb - R/W/noCS

*Delphi MT62.1 CAN (FID: 146) with NXP SPC5634 1.5Mb - R/W/noCS

*Delphi MT62.1 JAC CAN (FID: 408) with NXP SPC5634 1.5Mb - R/W/noCS

*Delphi MT80 (FID: 61) with Infineon Tricore TC1762 1.5Mb - R/W/CS

*Delphi MT92/MT92.1 (FID: 86) with Infineon Tricore TC17xx 2Mb/2.5Mb - R/W/noCS

*Delphi MT95.1 (FID: 455) Changan with Infineon Aurix TC367 4Mb - R/W/CS

*Delphi MT95.1 (FID: 456) ECU#1 Tank with Infineon Aurix TC367 4Mb - R/W/noCS

*Delphi MT95.1 (FID: 457) ECU#2 Tank with Infineon Aurix TC367 4Mb - R/W/noCS

*AECS FC-34 DongFeng Type 1 (FID: 482) with NXP SPC563M64 1.5Mb - R/W/CS

*AECS FC-34 DongFeng Type 2 (FID: 483) with NXP SPC563M64 1.5Mb - R/W/CS

*AECS FC-34 IKCO (FID: 481) with NXP SPC563M64 1.5Mb - R/W/CS

*AECS FC-34 JAC (FID: 476) with NXP SPC563M64 1.5Mb - R/W/CS

*AECS FC-34 Jinbei/Brilliance (FID: 472) with NXP SPC563M64 1.5Mb - R/W/CS

*AECS FC-50 DongFeng (FID: 468) with NXP SPC563M64 1.5Mb - R/W/CS

Bitbox Dongle & Bitbox Module for China Diesel CAN

FIDs: 145, 510

Software module for reading and writing Delphi ECUs internal flash memory for China vehicles with diesel engines.

Delphi DCM3.7AP GWM/Haval (FID: 145)

This ECU is based on MCU Renesas SH72513 with internal flash memory 2.0 Mb. Allows reading and writing by CANbus with checksumm correction on writing.

Delphi DCM7.24 Yuchai/DongFeng/Foton (FID: 510)

This ECU is based on MCU Infineon Aurix TC277T with internal flash memory 4.0 Mb. Allows FullFlash reading and writing of calibration area by CANbus with checksumm correction on writing.

Other ECU types will be added by possibilities.

Bitbox Dongle & Bitbox Module for China Siemens Petrol

FID: 83, 484, 487, 488, 489, 490, 491, 492, 496, 497, 501

Software module for reading and writing Siemens/Continental ECUs internal flash memory for China vehicles with petrol engines.

Continental Simos 9.5 (FID: 83)

ECU Simos 9.5 is based on MCU C167 with external flash memory 512 Kb. It allows to virtual read fullflash, write calibration area via CANbus and checksumm correction on writing.

Continental Easy U2 Geely (FID: 484)

ECU Continental Easy U2 Geely is based on MCU SPC563M60 with internal flash memory 1.5Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U2 Mahindra (FID: 491)

ECU Continental Easy U2 Mahindra is based on MCU SPC563M60 with internal flash memory 1.5Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U2.5 Foton (FID: 497)

ECU Continental Easy U2.5 Foton is based on MCU SPC563M60 with internal flash memory 1.5Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U2.5 SGMW (FID: 487)

ECU Continental Easy U2.5 SGMW is based on MCU SPC563M60 with internal flash memory 1.5Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U2W SGMW (FID: 489)

ECU Continental Easy U2W SGMW is based on MCU SPC563M60 with internal flash memory 1.5Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U2+ Mahindra (FID: 501)

ECU Continental Easy U2+ Mahindra is based on MCU SPC563M64 with internal flash memory 1.5Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U3 Mahindra (FID: 490)

ECU Continental Easy U3 is based on MCU SPC564A70 with internal flash memory 2.0Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U3.6 SGMW (FID: 488)

ECU Continental Easy U3.6 SGMW is based on MCU SPC564A70 with internal flash memory 2.0Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U3D/U3E SGMW (FID: 496)

ECU Continental Easy U3D/U3E SGMW is based on MCU SPC563M64 with internal flash memory 1.5Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Continental Easy U SDI Geely (FID: 492)

ECU Continental Easy U SDI Geely is based on MCU SPC564A80 with internal flash memory 4.0Mb. It allows to read and write of calibration area via CANbus and checksumm correction on writing.

Bitbox Dongle & Bitbox Module for China LinControl Petrol

FIDs: 475, 499, 500

Software module for reading and writing LinControl ECUs internal flash memory for chinesse vehicles with petrol engines.

Work is possible by OBD2 and on the BENCH. Some vehicles with GateWay will require BENCH connection for reading.

LinControl LEC4AF/LEC4AP (FID: 475)

ECUs LinControl LEC4AF and LEC4AP are based on MCU SPC563M64 with internal flash memory 1.5Mb and used in different vehicles from chinesse market. It allows FullFlash reading and writing of calibration area via CANbus. No CS is used in these ECUs.

LinControl LEC4AF JAC (FID: 499)

ECU LinControl LEC4AF is based on MCU SPC563M64 with internal flash memory 1.5Mb and used in JAC and Moskvich petrol vehices. It allows FullFlash reading and writing of calibration area via CANbus. No CS is used in this ECU.

LinControl LEC4GD JAC (FID: 500)

ECUs LinControl LEC4GD is based on MCU SPC563M64 with internal flash memory 1.5Mb used in JAC petrol vehices. It allows FullFlash reading and writing of calibration area via CANbus. No CS is used in this ECU.

Other ECU types will be added by possibilities.
