Bitbox Dongle & Bitbox Module for China Diesel CAN Work with Scanmatik 2 PRO SM2 Pro SM3 PRO Programmer

FIDs: 145, 510

Software module for reading and writing Delphi ECUs internal flash memory for China vehicles with diesel engines.

Delphi DCM3.7AP GWM/Haval (FID: 145)

This ECU is based on MCU Renesas SH72513 with internal flash memory 2.0 Mb. Allows reading and writing by CANbus with checksumm correction on writing.

Delphi DCM7.24 Yuchai/DongFeng/Foton (FID: 510)

This ECU is based on MCU Infineon Aurix TC277T with internal flash memory 4.0 Mb. Allows FullFlash reading and writing of calibration area by CANbus with checksumm correction on writing.

Other ECU types will be added by possibilities.
