Bitbox Dongle & Bitbox Module for Kia/Hyundai Diesel Work with Scanmatik 2 PRO SM2 Pro SM3 PRO Programmer

FID: 37, 42, 41, 39, 343

Module for OBD reflash for ECUs used in diesel Kia/Hyundai vehicles with Delphi and Denso ECUs.

Kia/Hyundai Denso Diesel SH72546 (FID: 42)

ECU based on MCU Renesas SH72546 with internal memory 3.75Mb.

Allows to real and virtual read and write FullFlash via CAN-bus with CHK calculation. Recovery is possible from any state.

Supported vehicles:

Hyundai Grand Starex H-1 (TQ) 2.5 CRDI Euro6
Hyundai H350 (EU) 2.5 CRDI Euro6
Hyundai H100 Porter (HR) 2.5 CRDI Euro6
Kia Bongo/K2500 2.5 CRDI Euro6

Kia/Hyundai Delphi DCM6.2AP (FID: 41)

ECU based on MCU NXP SPC5674 with internal memory 4Mb.

Allows to read fullflash and write calibration area via CAN-bus with CHK calculation.

Supported vehicles:

Hyundai i20 (GB) 1.1 CRDI Euro6
Kia Rio (UB) 1.1 CRDI Euro6

Kia/Hyundai Delphi DCM6.2AP BSL (FID: 343)

ECU based on MCU NXP SPC5674 with internal memory 4Mb.

Allows to read fullflash and write calibration area via CAN-bus with CHK calculation in BSL mode. Also available to recovery ECU damaged by OBD. Required full flash (Read from FID 41 is suitable) full readout from OBD.

Kia/Hyundai Delphi DCM3.7AP (FID: 39)

ECU based on MCU Renesas SH72513 with internal memory 2Mb.

Allows to read FullFlash and write calibration area via CAN-bus with CHK calculation.

Supported vehicles:

Hyundai H-1 (TQ) 2.5 CRDi Euro4/5
Hyundai i20 (PB) 1.1 CRDi Euro5
Hyundai i20 (PB) 1.4 CRDi Euro4/5
Hyundai i30 (GD) 1.4 CRDi Euro5
Hyundai iX20 (JC) 1.4 CRDi Euro5
Hyundai H100/Porter (HR) 2.5 CRDi Euro5
Kia Rio (UB) 1.1 CRDi Euro5
Kia Rio (UB) 1.4 CRDi Euro5
Kia Cee'd (JD) 1.4 Euro5
Kia Venga (YN) 1.4 CRDi Euro5
Kia Bongo/K2500 (PU) 2.5 CRDI Euro5

Kia Delphi DCM3.2AP (FID: 37)

ECU based on MCU Motorola MPC563 +external flash AM29BDD160GB with total memory adress area 2.5Mb.

Allows to read FullFlash, write with CHK calculation by CAN-bus.

Supported vehicles:

Kia Bongo 2.9 CRDI Euro4
Kia Carnival 2.9 CRDI Euro4
Kia Sedona 2.9 CRDI Euro4
